Nokia Car Mode application revs up with MirrorLink

Published by at

Today, at the IAA (a car industry event), Nokia announced Car Mode, an application designed for the in-car use of Nokia smartphones. It offers simplified access to Nokia Drive (voice-guided car navigation with Nokia Maps), music and voice calling functionality. In addition, the application also supports MirrorLink (previously known as Terminal Mode), which allows for a rich connection between phone and car. The application, which has been developed in Qt, will be available for download from the Ovi Store in Q4 for Symbian Belle devices and the Nokia N9. Update: added screenshots of Nokia Car Mode.

In essence, the application provides large on screen controls to make it easier to use when driving. There are three key use cases: navigation, music and calling. The navigation element is based on the Drive module of Nokia Maps, the music element is based on the Music application (sharing the same music library) and the calling elements are based on the Phone and Contacts applications.

Having a dedicated application for in-car usage make sense, but the real benefits come when it is combined with integration into the car's hardware. This is what the application's support for MirrorLink is all about. The MirrorLink technology enables the replication of the screen of the phone to a head unit and will also connect the phone to the car's audio system. The head unit, which is generally made up of a dashboard mounted touchscreen and associated buttons, can send input to the phone. In addition, the phone can also use the car sensors (e.g. GPS and microphones), to augment its own built in sensors.

Nokia 701 with Car Mode

A Nokia 701 being plugged into an Alpine head unit via the microUSB port.
Once upgraded to Symbian Belle, all Symbian^3 devices (Nokia N8, C7, E7, E6, X7, C6-01 etc.) will be able to use the application.

In practice, this means that key phone functionality and applications appear to be fully integrated into the car's own systems, going a long way beyond what is possible with current Bluetooth-based systems. The phone holds the data and is doing most of the hard work, but there should be no need to actually interact with the phone directly. Rather, everything can be controlled from the head unit's touchscreen and associated controls.

MirrorLink is an open standard (and trademark) of the Car Connectivity Consortium (CCC). The intention is that MirrorLink head units will work with any phone that supports the standard (i.e. akin to Bluetooth or USB). Nokia is just the first phone manufacturer to implement MirrorLink support. Other members of the CCC (HTC, LG, Sony Ericsson, Motorola Mobility) are likely to follow in due course. We are likely to see further developments at the Car Connectivity Consortium Summit, which takes place at the end of the month in Chicago.

MirrorLink was previously known as Terminal Mode, a technology that was initially developed in Nokia Research and Development labs. We've previously written about the technology here and here.


Nokia Car Mode application demoed

This video, from Nokia, shows Nokia Car Mode being used with Alpine's ICS-X8 App Link Station. The phone is plugged into the Alpine head unit, which automatically starts the Nokia Car Mode application.


Nokia Car Mode application screenshots

These screenshots show the Nokia Car Mode application running on a Nokia N9. The application will look near identical on the Symbian devices and can be used in ether portrait or landscape orientation.

Nokia Car Mode can be used in stand alone mode (i.e. when sitting in a holder or sitting on the dashboard) or in conjunction with a full head unit (i.e. via the MirrorLink functionality).

The navigation functionality provides a simplified form of Nokia Maps. As shown in the screenshot below, the size of the on-screen controls are increased and larger fonts are used for the text labels.

Nokia Car Mode screenshots

The aim of the simplification is to make the application easy to use when in the car. In the screenshot below the controls have been reduced to a back button (toolbar) and start navigation button.

Nokia Car mode maps

The same simplification and optimisation is found in the music portion of the application. In particular the size of the music controls, on screen indicators and descriptive text is increased.

Nokia Car mode Music

Nokia Car mode Music

In addition to the music playback screen the controls for accessing the music library have been optimised. Large on-screen menus and buttons allow you to navigate through and select music from the music library and playlists.

Nokia Car mode Music

Nokia Car mode Music


Alpine ICS-X8 App Link Station

The first commercial MirrorLink head units to be announced is Alpine's ICS-X8 App Link Station. It was also announced today at the IAA event and has been developed under a strategic partnership agreement between Alpine and Nokia.

The Alpine ICS-X8 is a head unit that can be retrofitted to supported cars to add MirrorLink and Bluetooth hands-free phone functionality. It has a high resolution seven inch touchscreen. Other features include a built in Bluetooth module, echo cancellation and microphone gain adjustment (allowing sound quality to be tweaked for virtually any car interior) and the ability for the software to be updated via a USB connection.

Alpine ICS-X8

As part of the ICS-X8 package, Alpine provides sound equipment that reflects the company's heritage in this area:

The ICS-X8 continues Alpine’s legacy of high sound quality, featuring a 50W x 4 amplifier, three high voltage pre-amp outputs, 9-band Parametric EQ, digital time correction, and digital crossover. To tackle the lossy nature of compressed digital music, Alpine’s exclusive MediaXpander™ technology ensures richer music playback more true to the original recording. These sound quality features are available as well for Nokia Music playback.

The ICS-X8 will be available in November through authorised Alpine dealers.
